    Hydraulic Pneumatic Door Window Punching Tool 2.2 Ton Capacity

    Ask Lasest Price
    Price : Negotiable
    Brand Name : XuanQing
    Delivery Time : 10-15 work days
    Payment Terms : TT
    Supply Ability : 3000000pcs/mon
    • Product Details
    • Company Profile

    Hydraulic Pneumatic Door Window Punching Tool 2.2 Ton Capacity

    2.2 Ton Capacity 2.5*20mm Drain Hole Hydraulic Pneumatic Door And Window Punching Tool

    Description:


    The 2.2 ton Capacity 2.5*20mm Drain Hole Hydraulic Pneumatic Door and Window Punching Tool is a powerful tool for creating drain holes. Combines hydraulic and pneumatic power. Sturdy and easy to use.

    Quick Details

    Capacity: 2.2 tons.

    Hole size: 2.5*20mm.

    Hydraulic and pneumatic power.

    For door and window drain holes.

    Sturdy construction.

    Easy to operate.

    Specification

    Product name

    Portable Hydraulic pneumatic Punch Machine
    Model Numbering DesignationDrilling Tools, Punchers, Double Hole Punchers
    Exhaust VentHandle
    Capacity2.1 ton (2.2mm thick) Aluminium, 1.6 ton (2.0mm thick) Mild Steel, 980kg (1.5mm thick) Stainless Steel
    TypeHoles Puncher
    Discharge Pressure of Air Compressor6-9 bar(0.6-0.9 MPa)
    Weight3.0 kg (2.1ton Capacity),2.5kg (1.6ton Capacity),2.0kg (980kg Capacity)
    Punched Hole Diameter2.5*20mm
    Holes DistanceThe hole distance (<40mm) can be positioned according to the profile
    Length330mm (13.0 in.)
    Packing and Delivery
    Hydraulic Pneumatic Door Window Punching Tool 2.2 Ton Capacity
    Hydraulic Pneumatic Door Window Punching Tool 2.2 Ton Capacity

    No special requirements for packaging, tandard export packing: carton box

    If there are other requirements, packaging can be done according to customer requirements.
